Kui olete töövõtja, kellel on palju erinevaid kliente, või kui teie enda tegevuse maht ja korraldus nõuavad mitmekülgsust, siis oleme ehitanud just teile mõeldud heinapressi. Kui toodate põhku, heina, kuivsilo või silo – ühte neist või natuke igaühest, siis saate siit parima lahenduse. G-, M- ja R-seeria rullipressid on kõige mitmekülgsemad muudetava kambrimahuga rullipressid.
Specifications |
||||
|---|---|---|---|---|
| Select up to 4 models to compare specifications | John Deere V451G Variable Chamber Balers |
| Density control | Softcore - 0-bar density/diameter adjustable from the monitor | |||
|---|---|---|---|---|
| Bale size indication | ||||
| Regular pickup - Bars | Four |
| Size | Diameter 1.0 to 1.65 m 3.3 to 5.4 ft Width 1.21 m 3.97 ft |
|---|
| Base weight | 3700 kg 8157 lb |
|||
|---|---|---|---|---|
| Length | Gate closed With bale ramp - 5.31 m 17.4 ft |
|||
| Height | ||||
| Width |
| Forming chamber | Variable - six laced belts + two front rolls + starter roll | |||
|---|---|---|---|---|
| Density control | Setting - from the baler Softcore - 0-bar density/diameter adjustable from the monitor |
|||
| Bale size indication |
| Type | ||||
|---|---|---|---|---|
| Width | Inside Tine to tine - 1.92 m 6.3 ft 2.2 m 7.22 ft |
|||
| Drive | Cam track | |||
| Bars | Four | |||
| Gauge wheels | Castor action | |||
| Strippers material | Galvanized steel | |||
| Windrow compressor system | Compressor shield |
| Rotor | RotoFlow HC | |||
|---|---|---|---|---|
| Unplugging system | Manual wrench plus rotor clutch |
| Type | ||||
|---|---|---|---|---|
| Width | ||||
| Drive | ||||
| Bars | ||||
| Gauge wheels | ||||
| Strippers material | ||||
| Windrow compressor system |
| Rotor | ||||
|---|---|---|---|---|
| Knives | ||||
| Knife spacing | ||||
| Unplugging system |
| Rotor | ||||
|---|---|---|---|---|
| Knives | ||||
| Knife spacing | ||||
| Unplugging system |
| Control | From monitor | |||
|---|---|---|---|---|
| Type | Standard Net tying only Capacity for two net rolls Optional Net and twine tying Net system located on tailgate |
|||
| Twine arms | Optional - two independent twine arms | |||
| Twine ball capacity | Eight twine spools |
| Monitor console for tractor | ||||
|---|---|---|---|---|
| Gate closed | With BaleTrak | |||
| Bale forming | With BaleTrak | |||
| Bale size | Yes | |||
| Near full bale | With BaleTrak | |||
| Full bale | With BaleTrak | |||
| Auto wrap | Yes | |||
| Oversize bale | With BaleTrak |
| Standard | 15/55-17 | |||
|---|---|---|---|---|
| Optional | 500/50-17 |
| Drive protection | Shearbolt or camclutch | |||
|---|---|---|---|---|
| PTO speed | 540 rpm 102 kW 137 hp |
| Maintenance/chains | Optional chain lubrication Bearings greasing - centralized greasing zerks |
|||
|---|---|---|---|---|
| Date collected | 2-February-2018 |
